Mersen Brand Surge Protection Device STPT2-40K1000V-YPV

Protect Your Photovoltaic Investments with Mersen’s Surge-Trap® Pluggable STPT2 Series

Series: Surge-Trap® Pluggable STPT2 Series – 40kA PV
Model: 83020140 STPT2-40K1000V-YPV
Type: SPD Type 2, 40kA
Voltage: Ucpv 1060V
Configuration: 3 Poles, 3 Modules, Pluggable

Approvals & Standards:

• EN 50539-11
• UL 1449 4th Ed.
• IEC 61643-31

Key Features & Benefits:

• Advanced Overvoltage Protection: Mersen’s STP T2 40 PV series is engineered to provide robust overvoltage protection for photovoltaic (PV) systems, utilizing an optimized dynamic thermal disconnection system that eliminates the need for additional overcurrent protection.
• High Short-Circuit Withstand Rating: Capable of withstanding high short-circuit conditions, ensuring reliable protection without the need for a back-up fuse.
• Versatile Applications: Suitable for all PV installations, including large-scale systems, rooftop setups, and self-consumption (off-grid) DC installations.
• Specific Multipole Products: Tailored for multiple MPPT (Maximum Power Point Tracker) inverters, ensuring compatibility and optimal performance.
• Maximum Discharge Current: 40 kA (8/20μs), providing superior protection against surges.
• Nominal Discharge Current: 10 kA, 20 kA (8/20μs), ensuring reliable performance under various conditions.
• Voltage Range: Ucpv options of 65, 80, 660, 1060 Vdc, and 1500 Vdc, offering flexibility for different system requirements.
• SCCR Ratings: 50 kA, 65 kA, 100 kA (UL 1449 4th Ed.), ensuring high short-circuit current ratings.
• Convenient Installation: DIN-rail mountable with a plug-in format for easy installation and maintenance.
• End-of-Life Indicators: Visual and remote indicators for timely maintenance and replacement.
• Reversible Chassis: Allows cable entry from above or below, providing installation flexibility.
• Mechanically Coded Cartridges: Prevents cartridge replacement errors, ensuring safety and reliability.

Applications:

• Ideal for use in photovoltaic and wind energy systems, providing comprehensive protection for your renewable energy investments.

Available From:

• Authorized Dealer: Shansen Traders, Coimbatore, Tamil Nadu, India

Equip your PV systems with the Mersen Brand Surge Protection Device 83020140 STPT2-40K1000V-YPV and experience unmatched protection and reliability. Whether for large-scale installations or small off-grid setups, this device ensures your system stays protected and operates at peak efficiency. Visit Shansen Traders today to secure your Mersen solar energy solutions!

Download Product Brochure
